BODY
Foldable flood linear light, The very fashion and uniegue design linear luminary with diffused light that stands can be widely used for commercial & residential
LED SOURCES(TOP LED BRAND USED)
OSRAM SMD
CRI: 90.95.97
CCT:2700K,3000K,4000K,5000K,6000K
SDCM<3
Other CRl, CCT options available per requests
DRIVER
used with DC48V system
Dimming options: 0/1-10V, DALI (DALI DT6/ DALI DT8),Phase Cut,CASAMBI
OPTIC
Reflector/Lens
Beam angle: 15°/24°/36°
| Input voltage (volts) | DC48V | Protection Index | IP20 | |||
| Beam angle | 15°/ 24°/ 36° | UGR | <16 | |||
| Color temperature | 2700K/3000K/4000K/6000K/3CCT | Tilt | 90° | |||
| Color rendering index (Ra) | >90/ >95/ >97 | Rotation | 355° | |||
| Operating temperature | -25°C-50° | MacAdam step | 2-3 | |||
| Rated life hours | 35,000-50,000 LM80 | Finishes | White/Black | |||
| LED chip | COB | Lighting body material | Aluminum | |||
| Certification | CE,CB,TUV,CCC,SAA | Warranty | 5 Years |
